Specifications
General Specifications
Platform:
Boxed Processor
Market Segment:
Mainstream Desktop
Product Family:
AMD Ryzen™ Processors
Product Line:
AMD Ryzen™ 5 5000 G-Series Desktop Processors with Radeon™ Graphics
Consumer Use:
Yes
Commercial Use:
No
Regional Availability:
Global, China, NA, EMEA, APJ, LATAM
Former Codename:
"Cezanne"
Architecture:
"Zen 3"
# of CPU Cores:
6
Multithreading (SMT):
Yes
# of Threads:
12
Max. Boost Clock:
Up to 4.4GHz
Base Clock:
3.6GHz
L1 Cache:
384KB
L2 Cache:
3MB
L3 Cache:
16MB
Default TDP:
65W
AMD Configurable TDP (cTDP):
45-65W
Processor Technology for CPU Cores:
TSMC 7nm FinFET
CPU Compute Die (CCD) Size:
180mm²
Package Die Count:
1
Unlocked for Overclocking:
Yes
CPU Socket:
AM4
Thermal Solution (PIB):
AMD Wraith Stealth
Thermal Solution (MPK):
AMD Wraith Stealth
Max. Operating Temperature (Tjmax):
95°C
Launch Date:
1/8/2024
*OS Support:
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
PCI Express® Version:
PCIe® 3.0
NVMe Support:
Boot, RAID0, RAID1, RAID10
System Memory Type:
DDR4
Memory Channels:
2
Max. Memory:
128GB
System Memory Subtype:
UDIMM
Max Memory Speed:
2x1R DDR4-3200
2x2R DDR4-3200
4x1R DDR4-2933
4x2R DDR4-2667
Graphics Capabilities
Integrated Graphics:
Yes
Graphics Model:
Radeon™ Graphics
Graphics Core Count:
7
Graphics Frequency:
1900 MHz
