Specifications
Application
Intel
LGA1700/1200/1151/1150/1155
AMD
AM5/AM4
Net Weight
1476 g
Radiator Dimensions
282 x 120 x 27 mm (L x W x H)
Radiator Material
Aluminum
Tube length
410 mm
Pump Dimensions
89 x 78 x 53 mm (L x W x H)
Pump Speed
3400 RPM±10%
Pump Noise
21 dB(A)
Pump Connector
3-pin
Pump Rated Voltage
12 VDC
Pump Rated Current
0.35 A
Pump Power Consumption
4.2 W
Fan Dimensions
120 x 120 x 25 mm (L x W x H)
Fan Speed
600~2400 RPM±10%
Fan Airflow
72.04 CFM
Fan Air Pressure
3.48 mmAq
Fan Noise
=38.71 dB(A)
Fan Connector
4-pin PWM
Bearing Type
Hydro Bearing
Fan Rated Voltage
12 VDC
Fan Rated Current
0.22 A
Fan Power Consumption
2.64 W
LED Type
Addressable RGB LED
LED Connector
3-pin(+5V-D-G)
LED Rated Voltage
5 VDC
LED Power Consumption
2.55 W(PUMP)/ 2.1 W(FAN x 2)
Display Type
LED Digital Display
