Specifications
Essentials
Product Collection:
Intel® Core™ i3 Processors (14th gen)
Vertical Segment:
Desktop
Processor Number:
i3-14100F
Lithography:
Intel 7
Use Conditions:
PC/Client/Tablet
CPU Specifications
Total Cores:
4
# of Performance-cores:
4
# of Efficient-cores:
0
Total Threads:
8
Max Turbo Frequency:
4.7 GHz
Performance-core Max Turbo Frequency:
4.7 GHz
Performance-core Base Frequency:
3.5 GHz
Cache: 12 MB Intel® Smart Cache
Total L2 Cache:
5 MB
Processor Base Power:
60 W
Maximum Turbo Power:
110W
Supplemental Information
Marketing Status:
Launched
Launch Date:
Q1'24
Embedded Options Available:
Yes
Memory Specifications
Max Memory Size (dependent on memory type):
192 GB
Memory Types:
Up to DDR5 4800 MT/s, Up to DDR4 3200 MT/s
Max # of Memory Channels:
2
Max Memory Bandwidth:
76.8 GB/s
Expansion Options
Direct Media Interface (DMI) Revision:
4.0
Max # of DMI Lanes:
8
Scalability:
1S Only
PCI Express Revision:
5.0 and 4.0
PCI Express Configurations
: Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes:
20
Package Specifications
TJUNCTION:
100°C
Package Size:
45.0 mm x 37.5 mm
Security & Reliability
Intel® Standard Manageability (ISM):
Yes
Intel® Control-Flow Enforcement Technology:
Yes
Intel® AES New Instructions:
Yes
Secure Key:
Yes
Intel® OS Guard:
Yes
Execute Disable Bit:
Yes
Intel® Boot Guard:
Yes
Mode-based Execute Control (MBEC):
Yes
Intel® Virtualization Technology (VT-x):
Yes
Intel® Virtualization Technology for Directed I/O (VT-d):
Yes
Intel® VT-x with Extended Page Tables (EPT):
Yes
