Specifications
Essentials
Product Collection:
Intel® Core™ i5 Processors (14th gen)
Code Name:
Products formerly Raptor Lake
Vertical Segment:
Desktop
Processor Number:
i5-14400
Lithography:
Intel 7
Use Conditions:
PC/Client/Tablet
CPU Specifications
Total Cores:
10
# of Performance-cores:
6
# of Efficient-cores:
4
Total Threads:
16
Max Turbo Frequency:
4.7 GHz
Performance-core Max Turbo Frequency:
4.7 GHz
Efficient-core Max Turbo Frequency:
3.5 GHz
Performance-core Base Frequency:
2.5 GHz
Efficient-core Base Frequency:
1.8 GHz
Cache:
20 MB Intel® Smart Cache
Total L2 Cache:
9.5 MB
Processor Base Power:
65 W
Maximum Turbo Power:
148 W
Supplemental Information
Marketing Status:
Launched
Launch Date:
Q1'24
Embedded Options Available:
Yes
Memory Specifications
Max Memory Size (dependent on memory type):
192 GB
Memory Types:
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels:
2
Max Memory Bandwidth:
76.8 GB/s
GPU Specifications
GPU Name?:
Intel® UHD Graphics 730
Graphics Max Dynamic Frequency:
1.55 GHz
Graphics Output:
eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units:
24
Max Resolution (HDMI):
4096 x 2160 @ 60Hz
Max Resolution (DP):
7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)?:
5120 x 3200 @ 120Hz
DirectX* Support:
12
OpenGL* Support:
4.5
OpenCL* Support:
3.0
Multi-Format Codec Engines:
1
Intel® Quick Sync Video:
Yes
Intel® Clear Video HD Technology:
Yes
# of Displays Supported:
4
Device ID:
0x4682/0xA782
Expansion Options
Direct Media Interface (DMI) Revision:
4.0
Max # of DMI Lanes:
8
Scalability:
1S Only
PCI Express Revision:
5.0 and 4.0
PCI Express Configurations:
Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes:
20
Package Specifications
Sockets Supported:
FCLGA1700
Max CPU Configuration:
1
Thermal Solution Specification:
PCG 2020C
TJUNCTION:
100°C
Package Size:
45.0 mm x 37.5 mm
Advanced Technologies
Intel® Gaussian & Neural Accelerator:
3.0
Intel® Thread Director:
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU:
Yes
Intel® Speed Shift Technology:
Yes
Intel® Turbo Boost Technology:
2.0
Intel® Hyper-Threading Technology:
Yes
Intel® 64 ?:
Yes
Instruction Set:
64-bit
Instruction Set Extensions:
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States:
Yes
Enhanced Intel SpeedStep® Technology:
Yes
Thermal Monitoring Technologies:
Yes
Intel® Volume Management Device (VMD):
Yes
Security & Reliability
Intel® Standard Manageability (ISM):
Yes
Intel® Control-Flow Enforcement Technology:
Yes
Intel® AES New Instructions:
Yes
Secure Key:
Yes
Intel® OS Guard:
Yes
Execute Disable Bit:
Yes
Intel® Boot Guard:
Yes
Mode-based Execute Control (MBEC):
Yes
Intel® Virtualization Technology (VT-x):
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ?:
Yes
Intel® VT-x with Extended Page Tables (EPT):
Yes
